Our Facilities

Laboratories & Workshops

The Textile Department has got following laboratories/workshops. These laboratories/workshops are being utilized by different branches of textile department for conduct of regular practicals, research projects, product engineering, consultancy services etc.

Following are the major facilities in the department

Spinning Workshop
Spinning Maintenance Laboratory
Weaving Workshop
Textile Physics & Testing Laboratory
Man Made Textile Laboratory
Garment Manufacturing Laboratory
Pattern making Laboratory
Fashion Cad Laboratory
Dye House
Chemical Testing Laboratory
Computer colour matching laboratory
Textile Computer Laboratory
Textile Electronics Laboratory
Fashion Illustration Laboratory
Technical Textile Laboratory
Italian Technology & Training Centre
Rieter Test & Training Centre
Lubricant Testing Laboratory

1. Spinning Workshop

The spinning workshop is well equipped with state of art machinery, which facilitates students and faculty members for research & study purposes.

Rieter Comfor Compact Spinning K-40
Rieter Comber E-70 R
Rieter Autoleveller Draw Frame RSB-D 30
Murata Air Jet Spinning MJS 802
Schlafhorst Autocoro 288
Trumac / Trutzschler Blow room Line
Trumac DK-780 Card.
LMW Speed frame LF1400
KTTM Ring frame RXI 240C
LMW Ring frame LG 5/1
Peass Parallel / Soft Winding machine
Vijay Lakshmi – Two for One Twister
Fancy Twister
Ring Doubler.
Amsler Fancy yarn attachment
Xorella yarn conditioning
Zinser Ringframe 351 C3
Savio TFO

2. Spinning Maintenance Laboratory

A Spinning maintenance laboratory is equipped with latest machineries for practical & research purpose of students as well as faculty members.

The facilities under this spinning maintenance laboratory.

Flat End Milling machine
Flat Clamping machine
Flat Grinding machine
Roller mounting machine
Cots grinding machine
Arbour Flusing / Cleaning machine
Cot Checking Instrument
Cot mounting machine
Cot calendaring machine
Top Roller Greasing machine

3. Weaving Workshop

The workshop is well equipped with conventional to latest weaving machines for imparting practical training. The weaving machines are fully exploited for product development, research practicals etc. These maintenance equipments are also being used by the industry.

Following are the major facilities available

Sulzer projectile weaving machine with training models
Schlafhorst 338 winding machine
Mayer & Cie knitting machine
Design studio (Wonderweaves & Textronics)
Ruti C weaving machine
Cimmco auto loom
Harish Vivita Air jet weaving machine
Braiding machine
All types of conventional shuttle looms & Prepatory machine
CCI Tech. Sample Sizing, Sample warping & Sample loom set-up
Smit Rapier weaving machine
Dornier rapier weaving machine
Smit Air jet weaving machine
Auto sample loom, sizing, warping (CCI Taiwan make)
Pailung interlock Knitting machine
Liba sample warp knitting machine
Muller needle loom
Bonas Electronic Jacquard.
Savio Polar Winding Machine
Somet Air Jet Weaving Machine
KTM socks knitting machine
SuoHwan computerized flat knitting machine
Schoch Reed Display

4. Textile Physics & Testing Laboratory

The textile physics & testing laboratory is equipped with modern instruments that are used for testing of fibers to fabric.

Facilities available for testing & research purposes are

Uster AFIS PRO
Instron Universal Testing machine (5565)
Zweigle yarn hairiness tester
Zweigle yarn Friction tester
High Volume Instriments HFT (Premier)
Premier aQuara NL.
Premier Tensomax 7000
Yarn Evenness Tester with Imperfection Meter (Premier-IQ)
MESDAN Count CSP Tester (STRETCH 500 M)
Tensolab -Tensile Testing machine
Yarn Abrasion (MAG – SITRA Abrasion Test)
Cotton Trash analyzer
Microscopes
Carl Zeiss Stemi DVG Stereo Zoom Microscope
Carl Zeiss Trinoculler Stereo Zoom Microscope
Carl Zeiss Motorized Stereo Microscope
Carl Zeiss Image analysis system
Uster CSP Tester
Classimat
Handloom Fabric identification system
Microprocessor based Twist Tester
Fabric Pilling Tester (Autopill)

5. Man-Made Textile Laboratory

The laboratory is equipped with the following important instruments.

Air Texturising
Darw Texturising
Pilot Melt Spinning machine for Polypropylene Fibres.
Two Stage filament Yarn Drawing machine.
High Speed Draw winder
Solution Spinning Machine
Dynafil.M
Tensometer
Crape TFO
Air Covering Machine
Melt Spinning machine for Polyester and Polyamide fibres.
Melt Flow Index Tester
Density Gradient Column
Spinfinish Extraction Device

6. Dye House

Open bath beaker dyeing machine
High Temperature Beaker Dyeing machine
Laboratory jigger
Laboratory Winch
Rota dyer
Infra Colour Dyeing machine
2 Kg. Soft flow dyeing machine
10 Kg. Soft overflow dyeing machine
Fong’s Soft flow dyeing machine (10 Kg) (AII FIT-10)
Fong’s package dyeing machine(3 Kg) (LABWIN-3)
Single package dyeing machine
Garment dyeing machine
THE AIRFLOW AFE 50 Soft flow dyeing machine(50 Kg)
Single Colour Roto-flat printing machine
Transfer printing machine
Lab. Padding mangles and curing chambers
High Tempratures steamer. HT-U steamer
Mini Boiler

7. Chemical Testing Laboratory

The laboratory is well equipped for chemical processing of all types of fiber and fabric.

Facilities :

Mathis Labomat
Tessile Computer Colour Matching Systems
Premier Computer Colour Matching Systems
Treepoint Computer Colour Matching Systems
UV_Visible Spectrophotometer
Launder-O-Meter
Light Fastness Tester
Sublimation Fastness Tester
Flammability Tester
Crockmeter, Perspirometer
IFB front loading washing machine
Morapex extractor
Auto Dosing System
Laboratory Dying System

8. Computer Colour Matching Laboratory

Mathis Labomat
Premier Computer Colour Matching Systems
Treepoint Computer Colour Matching Systems
Super dye Computer Colour Matching Systems
UV_Visible Spectrophotometer
IFB front loading washing machine
Morapex extractor

9. Garment Manufacturing Laboratory

At present the laboratory has the following machines.

Single Needle High Speed Lock Stitch Machine
Single Needle Lockstitch with UBT & Servomotor
2 Needle High Speed Lock Stitch machine.
2 Needle 4 Thread High Speed Overlock machine
2 Needle 5 Thread High Speed Overlock machine
3 Needle Feed off the arm machine
2 Needle Chainstitch Belt Loop Making machine.
Bar tack machine.
Industrial Blind Stitch machine.
Button Hole machine
Chain stitch, Button Stitch machine.
4 Needle Chainstitch Waistband Attach machine
6 Needle 12 Thread Chain Stitch machine.
3 Needle 5 Thread Flat bed Flat Lock machine
3 Needle 5 Thread Cylinder Bed Interlock M/c.
Vacuum table With Steam Iron.
9 Needle 2 Head Computerized Embroidery machine

10. Pattern Making Laboratory

Dress Forms
Pattern making tools and accessories
Pattern Making tables
Fabric spreading & cutting tables
8″ Straight knife cloth cutting machine
4″Octagonal cutting machine

11. Fashion Cad Laboratory

Dell computers
Reach CAD & Fashion Studio
Richpeace Garment CAD & 3D Textile & Fashion CAD Software
Richpeace Plotter and Digitizer
Textronic Design 3D
Textronic Design studio
Wonderweaves Texprint Software
Lectra CAD Software
Embroidery Software

12. Fashion Illustration Laboratory

Special Tilted Drawing Boards
Mannequins
Display Stands
Display Boards

13. Technical Textile Laboratory

This Laboratory is well equipped to carry out research and development work in technical textiles

Facilities :

Mathis continuous coating range type KTF-S-500
Digital Bursting strength tester
Flammability Tester
Compression Anvils
Spectrophometer

14. Italian Technology Training Center

Savio TFO
Bianco Weft Straightener
Fadis Soft Winding Machine

15. Rieter Test And Training Centre

Air jet Spinning Machine – J20

16. Lubricant Testing Laboratory

Infrared Spectrometer
Autotitrator
